Low impedance 5" ceiling loudspeaker
☑ 5" double cone speaker. 12 W RMS@8 Ω
☑ Low profile aluminium grille
☑ Highly conductive quick-connect terminals
☑ Anti-fall system for installation assistance
FONESTAR SKY-5
51,81 €
Tasse incluse
Spedito entro 5/7 Giorni
Low impedance 5" ceiling loudspeaker
☑ 5" double cone speaker. 12 W RMS@8 Ω
☑ Low profile aluminium grille
☑ Highly conductive quick-connect terminals
☑ Anti-fall system for installation assistance
close
| FEATURES: | Low impedance ceiling loudspeaker. |
|---|---|
| Low profile frameless grille, constructed from rust resistant aluminium. Detachable, turn-lockable. The logo can be removed and the speaker can be painted. | |
| Fast connection terminals and high conductivity. | |
| Anti-fall system for installation assistance. | |
| Hook for safety cable. | |
| Stable, worm-gear ceiling brackets. | |
| Protection against dust and water. | |
| POWER: | 12 W RMS |
| 16 W MAX. | |
| SPEAKER: | 5'' polypropylene double cone diaphragm |
| RESPONSE: | 55-20.000 Hz @ -10 dB |
| 70-20.000 Hz @ -10 dB | |
| IMPEDANCE: | 8 Ω |
| SENSITIVITY: | 85 dB @ 1 W/1 m |
| CONNECTORS: | Highly conductive quick-connect terminals |
| For 0.4 ~ 4 mm² cross section cable | |
| SOUND PRESSURE: | 97 dB @ max. W/1m Continuos |
| 98 dB @ max. W/1m Peak | |
| COVERAGE ANGLE: | H/V (-6 dB): 60º@500Hz, 90º@1kHz, 60º@2kHz, 90º@4kHz |
| PROTECTIONS: | IP-44 in compliance with IEC 60529 |
| EN ISO 9227:2006 Neutral Salt Spray Test | |
| MATERIAL: | ABS (UV resistant) |
| Liquid paint aluminium grille | |
| OPERATION TEMPERATURE: | -20ºC ~ 70°C (48 h) |
| STORAGE TEMPERATURE: | 10ºC ~ 40°C |
| MAXIMUM HUMIDITY: | 95% |
| COLOUR: | White (RAL 9003) |
| DIMENSIONS: | Total loudspeaker: 214 mm Ø x 85 mm height |
| Grille section: 5 mm | |
| Recessed height: 80 mm | |
| Installation hole: 180 mm Ø | |
| Maximum ceiling thickness: 30 mm | |
| WEIGHT: | 0.5 kg |
| ACCESSORIES: | Installation template |
SKY-5
Scheda dati
- Pollici
- 5
Riferimenti specifici
- ean13
- 8422521027946
