Cone woofer 5,25" con un tweeter soft dome 0,75"
| General specifications | Speaker type | 2-way, Bass-reflex | |
|---|---|---|---|
| Frequency range (-10dB) | 62Hz - 20kHz | ||
| Nominal coverage | H | 120° | |
| V | 120° | ||
| Components | LF | 5.25" Cone | |
| HF | 0.75" Soft dome | ||
| Crossover | 3kHz | ||
| Power rating | NOISE | 75W | |
| PGM | 150W | ||
| Nominal impedance | 8Ω | ||
| Transformer taps | 100V | 30W (330Ω), 15W (670Ω), 7.5W (1.3kΩ) | |
| 70V | 30W (170Ω), 15W (330Ω), 7.5W (670Ω), 3.8W (1.3kΩ) | ||
| SPL | Sensitivity (1W; 1m on axis) | 88dB SPL | |
| Peak (Calculated) | 113dB SPL | ||
| I/O connectors | 1x Ceramic terminal block (3P) (input: +/-, Earth) | ||
| Shape | Rectangular | ||
| Cabinet material | ABS | ||
| Finish | VXS5-VA:Black / VXS5-VAW:White | ||
| Waterproof | IP35 | ||
| Dimensions | W | 176mm (6.9") | |
| H | 280mm (11.0") | ||
| D | 163mm (6.4") | ||
| Net weight | 3.6kg (7.9lbs) | ||
| Accessories | Wall / Ceiling mount bracket, Terminal cover | ||
| Others | Packaged in pairs | ||
| Certificate | CE, RoHS | ||
| EN54-24 compliance | Yes (DoP No. 0359-CPR-00406) | ||
