| Max SPL | 116 dB |
|---|---|
| Bandwidth | 120 Hz- 20 KHz |
| Transducers | LF : 1 x 4" |
| HF : 1 x 1.4" | |
| Weight | 1 kg / 2.2 lb |
| Directivity | H: 110° |
| V: 110° |
L-ACOUSTICS X4i
| Max SPL | 116 dB |
|---|---|
| Bandwidth | 120 Hz- 20 KHz |
| Transducers | LF : 1 x 4" |
| HF : 1 x 1.4" | |
| Weight | 1 kg / 2.2 lb |
| Directivity | H: 110° |
| V: 110° |
close
| Electroacoustic specs | |
|---|---|
| Usable bandwidth (-10 dB) | 120 Hz – 20 kHz ([X4]) |
| 65 Hz – 20 kHz ([X4_60]) | |
| Maximum SPL | 116 dB ([X4]) |
| 110 dB ([X4_60]) | |
| Nominal directivity (-6 dB) | 110° axisymmetric |
| Transducers | LF: 1 × 4″ neodymium |
| HF: 1 × 1.4″ | |
| Acoustical load | closed enclosure |
| Nominal impedance | 16 Ω |
| Physical specs | |
| Connectors | IN: 1 × 2-point screw terminal |
| LINK: 1 × 2-point screw terminal | |
| Rigging and handling | 2 M5 inserts for X-U4i |
| 2 M6 inserts for on-wall/on-ceiling rigging accessory | |
| In-wall/in-ceiling versions | |
| Safety | 1 M6 insert for secondary safety |
| Dimensions | 116 mm (4.6 in) / 116mm (4.6 in) / 99mm (3.9 in) |
| Weight (net) | 1 kg / 2.2 lb |
| Cabinet | premium grade Baltic birch plywood |
| Front | coated steel grill |
| Finish | dark grey brown Pantone 426 C |
| pure white RAL 9010 | |
| custom RAL code on special order | |
| IP | IP55 with connector sealing plate |
X4i
