| Max SPL | 123 dB ([X6i preset]) |
|---|---|
| Bandwidth | 54 Hz- 20 KHz ([X6i_50 preset]) |
| Transducers | LF : 1 x 6.5" |
| HF : 1 x 1.5" | |
| Weight | 6.3 kg / 14 lb |
| Directivity | H: 90° |
| V: 90° |
L-ACOUSTICS X6i
| Max SPL | 123 dB ([X6i preset]) |
|---|---|
| Bandwidth | 54 Hz- 20 KHz ([X6i_50 preset]) |
| Transducers | LF : 1 x 6.5" |
| HF : 1 x 1.5" | |
| Weight | 6.3 kg / 14 lb |
| Directivity | H: 90° |
| V: 90° |
close
| Electroacoustic specs | |
|---|---|
| Usable bandwidth (-10 dB) | 69 Hz – 20 kHz ([X6i preset]) |
| 54 Hz – 20 kHz ([X6i_50 preset]) | |
| Maximum SPL | 123 dB ([X6i preset]) |
| 117 dB ([X6i_50 preset]) | |
| Nominal directivity (-6 dB) | 90° axisymmetric |
| Monitor angle | 35°/55° |
| Transducers | LF: 1 × 6.5″ cone driver |
| HF: 1 × 1.5″ diaphragm compression driver, neodymium | |
| Acoustical load | LF: bass-reflex, L-Vents |
| HF: conical waveguide | |
| Nominal impedance | 8 Ω |
| Physical specs | |
| Connectors | IN: 1 × 2-point terminal block |
| LINK: 1 × 2-point terminal block | |
| Rigging and handling | 8 M6 inserts |
| Dimensions | 187mm (7.4 in) / 362mm (14.2 in) / 170mm (6.7 in) |
| Weight (net) | 6.3 kg / 14 lb |
| Cabinet | premium grade Baltic beech and birch plywood |
| Front | Coated steel grill |
| Acoustically neutral 3D fabric | |
| Finish | dark grey brown Pantone 426 C |
| pure white RAL 9010 | |
| custom RAL code on special order | |
| IP | IP55 |
