| Electroacoustic specs |
| Usable bandwidth (-10 dB) |
67 Hz – 20 kHz ([X8i preset]) |
| 43 Hz – 20 kHz ([X8i_40 preset]) |
| Maximum SPL1 |
129 dB ([X8i preset]) |
| 123 dB ([X8i_40 preset]) |
| Nominal directivity (-6 dB) |
90° axisymmetric |
| Monitor angle |
35°/55° |
| Transducers |
LF: 1 × 8″ cone driver |
| HF: 1 × 1.5″ diaphragm compression driver, neodymium |
| Acoustical load |
LF: bass-reflex, L-Vents |
| HF: conical waveguide |
| Nominal impedance |
8 Ω |
| Physical specs |
|
| Connectors |
IN: 1 × 2-point terminal block |
| LINK: 1 × 2-point terminal block |
| Rigging and handling |
8 M6 inserts |
| Dimensions |
240 mm (9.4 in) / 480 mm (16.9 in) / 217 mm (8.5 in) |
| Weight (net) |
11 kg / 24 lb |
| Cabinet |
premium grade Baltic beech and birch plywood |
| Front |
Coated steel grill |
| Acoustically neutral 3D fabric |
| Finish |
dark grey brown Pantone 426 C |
| pure white RAL 9010 |
| custom RAL code on special order |
| IP |
IP55 |
