EN 54 surface speaker with 100 V line transformer and low impedance
☑ Excellent sound quality
☑ Excellent finish and elegant design
☑ EN 54-24 certificate
☑ Prepared for outdoor use, protection against water and anti-corrosion materials.
FONESTAR SONORA-5TN-EN
158,09 €
Tasse incluse
Spedito entro 5/7 Giorni
EN 54 surface speaker with 100 V line transformer and low impedance
☑ Excellent sound quality
☑ Excellent finish and elegant design
☑ EN 54-24 certificate
☑ Prepared for outdoor use, protection against water and anti-corrosion materials.
close
| FEATURES: | Loudspeaker for voice alarm systems EN 54 |
|---|---|
| Low-impedance loudspeaker with 100 V line transformer. | |
| Prepared for outdoor use, waterproof and rustproof materials. | |
| INTENDED USE: | Loudspeaker for voice alarm systems |
| STANDARDS: | EN 54-24 certified |
| Fire detection and fire alarm systems - Part 24: components of voice alarm systems - Loudspeakers EN 54-24: 2008 | |
| POWER: | 80 W max., 40 W RMS |
| LOUDSPEAKERS: | 1 x 5 ¼" woofer |
| 1 x 1” tweeter | |
| RESPONSE: | 80-20,000 Hz |
| IMPEDANCE: | 40 W RMS@100 V (250 Ω) |
| 20 W RMS@100 V/70 V (500 Ω/245 Ω) | |
| 10 W RMS@100 V/70 V (1.000 Ω/490 Ω) | |
| 5 W RMS@100 V/70 V (2.000 Ω/980 Ω) | |
| 2'5 W RMS@70 V (1.960 Ω) | |
| Low Z: 8 Ω | |
| SENSITIVITY: | 86 dB @ 1 W/1 m |
| 74 dB @ 1 W/4 m | |
| MAXIMUM SOUND PRESSURE: | 99 dB @ max. W/1 m |
| 89 dB @ max. W/4 m | |
| COVERAGE ANGLE: | 135º H x 135º V @1kHz (-6 dB) |
| PROTECTION: | Type B (EN 54-24) |
| IP-66 in compliance with EN 60529 | |
| IEC 60068-2-11 Enviromental tests (Salt mist) | |
| MATERIAL: | ABS 5VB (UV resistance) |
| Aluminium mesh grille, with powder-coated finish | |
| Weather-resistant mount | |
| Stainless steel screws | |
| SWITCH: | W selector in high Z and low Z |
| CONNECTORS: | Euroblock in and out for cable 0.25 - 2.5 mm² cross section |
| TEMPERATURE RANGE: | -25ºC ~ 70ºC |
| COLOUR: | Black (RAL 9005) |
| DIMENSIONS: | Loudspeaker: 162 x 263 x 147 mm depth |
| Mount wall plate: 68 x 110 mm | |
| Loudspeaker with mount: 216 mm depth | |
| WEIGHT: | 2.2 kg |
| ACCESSORIES: | Adjustable fixing mountt ± 60º in all directions. |
| Steel safety cable |
SONORA-5TN-EN
Scheda dati
- Pollici
- 5
Riferimenti specifici
- ean13
- 8422521015929
