W-25 is a line array system which is made of two 5" woofers, a 1.4" compression driver and high performance low distortion compression driver with innovative horn design of wave phase philosophy. Wherever low frequency extension is required, a W-25 will integrate seamlessly with W-12P line array sub-bass system in a standard configuration. Each enclosure is equipped with rigging system, allowing flown array to be constructed rapidly and safely. W-25 is very versatile and scalable for a wide range.
IMPIANTO AUDIO CVR W-25 & W-12B/W-12BP
2.500,00 €
Tasse incluse
Spedizione 24/48h
W-25 is a line array system which is made of two 5" woofers, a 1.4" compression driver and high performance low distortion compression driver with innovative horn design of wave phase philosophy. Wherever low frequency extension is required, a W-25 will integrate seamlessly with W-12P line array sub-bass system in a standard configuration. Each enclosure is equipped with rigging system, allowing flown array to be constructed rapidly and safely. W-25 is very versatile and scalable for a wide range.
close
| TECHNICAL PARAMETERS | |
|---|---|
| Model | W-25 |
| Type | Two-way line array system |
| Frequency Response | 80Hz-20KHz±3dB |
| Power capacity | 200W(RMS)800W(PEAK) |
| Sensitivity | 91dB(1W/1M) |
| Max SPL | 110dB(PEAK/1M) |
| Drivers | LF 2×5"(135mm)woofer with 25mm (1in) coil |
| HF 1×1.4"neodymium compression driver with 34mm titanium diaphragm | |
| Nominal impedance | 16 ohm |
| Coverage | 110º H×9º V |
| Connectors | 2×NL4MP speakon |
| PHYSICAL PARAMETERS | |
| Dimensions | 410×163×248mm(W×H×D) |
| Packing Dimensions | 610×25.5×47.5mm(W×H×D)/0.07cbm |
| Enclosure Material | HDPE |
| Net weight | 6.5kg |
| Gross weight | 14.5kg |
| TECHNICAL PARAMETERS | |
| Model | W-12BP（Active） |
| Type | Line array subwoofer system |
| Frequency Response | 50Hz-600Hz±3dB |
| Power capacity | 700W(RMS)2800W(PEAK) |
| Sensitivity | 97dB(1W/1M) |
| Max SPL | 127dB(1W/1M) |
| Drivers | 1×12"(310mm)woofer with 100mm (4in) coil |
| Nominal impedance | 8 ohm |
| Connectors | 2×NL4MP speakon |
| PHYSICAL PARAMETERS | |
| Finish | Textured paint |
| Enclosure Material | Plywood |
| Dimensions | 408×480×494mm(W×H×D) |
| Packing Dimensions | 478×555×565mm(W×H×D)/0.15cbm |
| Net weight | 27.5kg |
| Gross weight | 29.5kg |
| POWER AMPLIFIER PARAMETERS | |
| Amplifier type | Switching mode amplifier,class D circuit |
| Power Output(RMS) | 2X900W/8ohm |
| Other functions | DSP Built-in |
| Weight | 3.6kg |
| Configuration | The amp module is built inside W-12BP,Which is designed to power 4/W-25+1/W-12BP |
W-25 & W-12B/W-12BP
1 Articolo
Nuovo
