Features
☑ 800 W continuous program power capacity
☑ 76 mm (3 in) copper voice coil
☑ 40 - 2000 Hz response
☑ 100 dB sensitivity
B&C 15PLB76 Woofer 15" 8 Ohm – Terminali Push Button
234,24 €
Tasse incluse
Spedito entro 5/7 Giorni
Features
☑ 800 W continuous program power capacity
☑ 76 mm (3 in) copper voice coil
☑ 40 - 2000 Hz response
☑ 100 dB sensitivity
close
| Specifications | |
|---|---|
| Nominal Diameter | 380 mm (15 in) |
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 6.2 Ω |
| Nominal Power Handling | 400 W |
| Continuous Power Handling | 800 W |
| Sensitivity | 100 dB |
| Frequency Range | 40 Hz - 2000 Hz |
| Voice Coil Diameter | 76 mm (3 in) |
| Winding Material | Copper |
| Former Material | Glass Fibre |
| Winding Depth | 16 mm (0.62 in) |
| Magnetic Gap Depth | 11 mm (0.4 in) |
| Flux Density | 1.15 T |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Nominal Diameter | 380 mm (15 in) |
| Minimum Impedance | 6.2 Ω |
| Continuous Power Handling | 800 W |
| Frequency Range | 40 Hz - 2000 Hz |
| Winding Material | Copper |
| Winding Depth | 16 mm (0.62 in) |
| Flux Density | 1.15 T |
| Nominal Impedance | 8 Ω |
| Nominal Power Handling | 400 W |
| Sensitivity | 100 dB |
| Voice Coil Diameter | 76 mm (3 in) |
| Former Material | Glass Fibre |
| Magnetic Gap Depth | 11 mm (0.4 in) |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Parameters | |
| Fs | 42 Hz |
| Re | 5 Ω |
| Qes | 0.26 |
| Qms | 5.9 |
| Qts | 0.25 |
| Vas | 164 dm³ (5.8 ft³) |
| Sd | 855 cm² (132.5 in²) |
| η0 | 4.5 % |
| Xmax | 5 mm |
| Xvar | 8 mm |
| Mms | 88 g |
| Bl | 22.1 Tm |
| Le | 1.3 mH |
| EBP | 162 Hz |
| Fs | 42 Hz |
| Qes | 0.26 |
| Qts | 0.25 |
| Sd | 855 cm² (132.5 in²) |
| Xmax | 5 mm |
| Mms | 88 g |
| Le | 1.3 mH |
| Re | 5 Ω |
| Qms | 5.9 |
| Vas | 164 dm³ (5.8 ft³) |
| η0 | 4.5 % |
| Xvar | 8 mm |
| Bl | 22.1 Tm |
| EBP | 162 Hz |
| Design | |
| Surround Shape | Triple Roll |
| Cone Shape | Exponential |
| Magnet Material | Ferrite |
| Spider | Single |
| Pole Design | T-Pole |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Recommended Enclosure | 100 dm³ (3.53 ft³) |
| Recommended Tuning | 50 Hz |
| Surround Shape | Triple Roll |
| Magnet Material | Ferrite |
| Pole Design | T-Pole |
| Recommended Enclosure | 100 dm³ (3.53 ft³) |
| Cone Shape | Exponential |
| Spider | Single |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Recommended Tuning | 50 Hz |
| Mounting and Shipping Info | |
| Overall Diameter | 393 mm (15.5 in) |
| Bolt Circle Diameter | 374 mm (14.7 in) |
| Baffle Cutout Diameter | 354 mm (13.9 in) |
| Depth | 169 mm (6.65 in) |
| Flange and Gasket Thickness | 16 mm (0.62 in) |
| Air Volume Occupied by Driver | 5.2 dm³ (0.18 ft³) |
| Net Weight | 8.6 kg (18.96 lb) |
| Shipping Units | 1 pcs |
| Shipping Weight | 9.9 kg (21.83 lb) |
| Shipping Box | 425x425x224 mm (16.73x16.73x8.82 in) |
| Overall Diameter | 393 mm (15.5 in) |
| Baffle Cutout Diameter | 354 mm (13.9 in) |
| Flange and Gasket Thickness | 16 mm (0.62 in) |
| Net Weight | 8.6 kg (18.96 lb) |
| Shipping Weight | 9.9 kg (21.83 lb) |
| Bolt Circle Diameter | 374 mm (14.7 in) |
| Depth | 169 mm (6.65 in) |
| Air Volume Occupied by Driver | 5.2 dm³ (0.18 ft³) |
| Shipping Units | 1 pcs |
| Shipping Box | 425x425x224 mm (16.73x16.73x8.82 in) |
ALT15PLB768M
Scheda dati
- Pollici
- 15"
Nuovo
