| FEATURES |
|---|
| ☑ 4.5 INCH CCAW VOICE COIL |
| ☑ 98 dB/SPL SENSITIVITY |
| ☑ 3400 WATT PROGRAM POWER HANDLING |
| ☑ FEM OPTIMIZED MOTOR AND SUSPENSIONS |
| ☑ 47,8 mm (1.9 INCH) PEAK TO PEAK |
| MAXIMUM EXCURSION |
| ☑ OPTIMIZED COOLING SYSTEM |
| ☑ DOUBLE SILICON SPIDER |
| ☑ ALUMINIUM DEMODULATING RING |
| ☑ TRIPLE ROLL SURROUND |
| ☑ ALTERNATIVE IMPEDANCE: 4 OHM |
SAN214.50
946,72 €
Tasse incluse
Spedito entro 5/7 Giorni
| FEATURES |
|---|
| ☑ 4.5 INCH CCAW VOICE COIL |
| ☑ 98 dB/SPL SENSITIVITY |
| ☑ 3400 WATT PROGRAM POWER HANDLING |
| ☑ FEM OPTIMIZED MOTOR AND SUSPENSIONS |
| ☑ 47,8 mm (1.9 INCH) PEAK TO PEAK |
| MAXIMUM EXCURSION |
| ☑ OPTIMIZED COOLING SYSTEM |
| ☑ DOUBLE SILICON SPIDER |
| ☑ ALUMINIUM DEMODULATING RING |
| ☑ TRIPLE ROLL SURROUND |
| ☑ ALTERNATIVE IMPEDANCE: 4 OHM |
close
GENERAL SPECIFICATIONS
| Nominal diameter | mm (in) | 530 (21) |
|---|---|---|
| Nominal Impedance | Ohm | 8 |
| Minimum impedance | Ohm | 6,8 |
| Program power | W | 3400 |
| AES Power rating | W | 1700 |
| Sensitivity | dB | 98 |
| Frequency range | Hz | 30 ÷1000 |
| Voice coil diameter | mm (in) | 115 (4.5) |
| Chassis material | Aluminium | |
| Magnet material | Neodymium | |
| Magnet dimensions OD x ID x h | mm (in) | 113 x 40 x 17 (4.45 x 1.57 x 0.67) |
| Coil material | CCAW | |
| Former material | Glass Fiber | |
| Cone material | Water Resistant Treated Paper + Water Proof Both Sides Treatment | |
| Surround material | Polycotton | |
| Xmax | mm (in) | 15,4 (0.60) |
| Xmech | mm (in) | 23,9 (0.94) |
| Gap height | mm (in) | 14 (0.55) |
| Voice coil winding height | mm (in) | 37,9 (1.49) |
| Driver displacement volume | l (ft³) | 10,3 (0.36) |
| Recommended Enclosure | l (ft³) | 296,1 (10.46) |
| Recommended Tuning | Hz | 35 |
70R10210
Scheda dati
- Pollici
- 21
