Features
☑ 2000 W continuous program power capacity
☑ 100 mm (4 in) copper voice coil
☑ 40 - 1500 Hz response
☑ 94 dB sensitivity
☑ Excursion optimized lead wires (woven through spider)
☑ Aluminium demodulating ring allows a very low distortion figure
☑ Double silicone spider with optimized compliance
☑ Ventilated voice coil gap for reduced power compression
B&C 12NBX100
325,74 €
Tasse incluse
Spedito entro 5/7 Giorni
Features
☑ 2000 W continuous program power capacity
☑ 100 mm (4 in) copper voice coil
☑ 40 - 1500 Hz response
☑ 94 dB sensitivity
☑ Excursion optimized lead wires (woven through spider)
☑ Aluminium demodulating ring allows a very low distortion figure
☑ Double silicone spider with optimized compliance
☑ Ventilated voice coil gap for reduced power compression
close
| Specifications | |
|---|---|
| Nominal Diameter | 320 mm (12 in) |
| Nominal Impedance | 4 Ω |
| Minimum Impedance | 4.5 Ω |
| Nominal Power Handling | 1000 W |
| Continuous Power Handling | 2000 W |
| Sensitivity | 94 dB |
| Frequency Range | 40 Hz - 1500 Hz |
| Voice Coil Diameter | 100 mm (4 in) |
| Winding Material | Copper |
| Former Material | Glass Fibre |
| Winding Depth | 25 mm (1 in) |
| Magnetic Gap Depth | 11 mm (0.43 in) |
| Flux Density | 1.1 T |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Nominal Diameter | 320 mm (12 in) |
| Minimum Impedance | 4.5 Ω |
| Continuous Power Handling | 2000 W |
| Frequency Range | 40 Hz - 1500 Hz |
| Winding Material | Copper |
| Winding Depth | 25 mm (1 in) |
| Flux Density | 1.1 T |
| Nominal Impedance | 4 Ω |
| Nominal Power Handling | 1000 W |
| Sensitivity | 94 dB |
| Voice Coil Diameter | 100 mm (4 in) |
| Former Material | Glass Fibre |
| Magnetic Gap Depth | 11 mm (0.43 in) |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Parameters | |
| Fs | 40 Hz |
| Re | 3.6 Ω |
| Qes | 0.23 |
| Qms | 7.05 |
| Qts | 0.22 |
| Vas | 46.5 dm³ (1.64 ft³) |
| Sd | 531 cm² (82 in²) |
| η0 | 1.27 % |
| Xmax | 10 mm |
| Xvar | 10 mm |
| Mms | 133 g |
| Bl | 23.04 Tm |
| Le | 1.35 mH |
| EBP | 174 Hz |
| Fs | 40 Hz |
| Qes | 0.23 |
| Qts | 0.22 |
| Sd | 531 cm² (82 in²) |
| Xmax | 10 mm |
| Mms | 133 g |
| Le | 1.35 mH |
| Re | 3.6 Ω |
| Qms | 7.05 |
| Vas | 46.5 dm³ (1.64 ft³) |
| η0 | 1.27 % |
| Xvar | 10 mm |
| Bl | 23.04 Tm |
| EBP | 174 Hz |
| Design | |
| Surround Shape | Triple Roll |
| Cone Shape | Exponential |
| Magnet Material | Neodymium Inside Slug |
| Spider | Double Silicone |
| Pole Design | T-Pole |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Recommended Enclosure | 40 dm³ (1.41 ft³) |
| Recommended Tuning | 50 Hz |
| Surround Shape | Triple Roll |
| Magnet Material | Neodymium Inside Slug |
| Pole Design | T-Pole |
| Recommended Enclosure | 40 dm³ (1.41 ft³) |
| Cone Shape | Exponential |
| Spider | Double Silicone |
| Woofer Cone Treatment | TWP Waterproof Both Sides |
| Recommended Tuning | 50 Hz |
| Mounting and Shipping Info | |
| Overall Diameter | 320 mm (12.6 in) |
| Bolt Circle Diameter | 300 mm (11.8 in) |
| Baffle Cutout Diameter | 280 mm (11 in) |
| Depth | 143 mm (5.63 in) |
| Flange and Gasket Thickness | 12 mm (0.47 in) |
| Air Volume Occupied by Driver | 4 dm³ (0.14 ft³) |
| Net Weight | 8.25 kg (18.19 lb) |
| Shipping Units | 1 pcs |
| Shipping Weight | 9.15 kg (20.17 lb) |
| Shipping Box | 360x360x200 mm (14.17x14.17x7.87 in) |
| Overall Diameter | 320 mm (12.6 in) |
| Baffle Cutout Diameter | 280 mm (11 in) |
| Flange and Gasket Thickness | 12 mm (0.47 in) |
| Net Weight | 8.25 kg (18.19 lb) |
| Shipping Weight | 9.15 kg (20.17 lb) |
| Bolt Circle Diameter | 300 mm (11.8 in) |
| Depth | 143 mm (5.63 in) |
| Air Volume Occupied by Driver | 4 dm³ (0.14 ft³) |
| Shipping Units | 1 pcs |
| Shipping Box | 360x360x200 mm (14.17x14.17x7.87 in) |
