| Amplification and power supply |
| Amplification class |
High-efficiency class D |
| Output power, all channels loaded |
16 x 1100 W at 4 ohms |
|
16 x 1300 W at 8 ohms |
|
16 x 700 W at 16 ohms |
| nominal power requirements |
16 A (200-240 V) 30 A (100-120 V) |
| mains connector |
32 A powerCON |
| Power supply model |
Universal Switched Mode Power Supply (SMPS) with Power Factor Correction (PFC) |
| Mains rating |
100 V - 240 V ±10%, 50-60 Hz |
| External DSP backup voltage input |
24 V DC |
| DSP |
| Digital Signal Processor (DSP) |
Gen.5 Dual SHARC 32-bit, floating point, 96 kHz sampling rate |
| I/O routing |
16 x 16 routing and summation matrix |
| Per output channel |
Built-in EQ station with 8 IIR, 4 FIR linear phase EQ filters |
| Array morphing (LF contour, zoom factor), Air absorption compensation filters |
| Internal IIR and FIR EQ algorithms for speaker phase linearization and improved impulse responses |
| Output delay from 0 to 1000 ms |
| Technologies |
| loudspeaker management |
L-DRIVE advanced system protection |
| amplifier management |
L-SMART adaptative power management |
| Latency |
|
| standard latency (analog/digital inputs) |
3.84 ms |
| low latency (analog/digital inputs) |
1.18 ms |
| Inputs |
| Milan-AVB |
16 channels from up to 16 streams (of up to 8 channels each) |
| AES/EBU |
2 channels AES/EBU (1 x AES3) with SRC |
| analog |
1 channel analog |
| connections |
2 etherCON 1 Gb/s I/O+ control 1 male 12-point terminal block (AES3 or Ana input/link + GPIO) |
| Outputs |
|
| loudspeaker connections |
1 SC32 connector |
| Circuits protection |
| Mains and power supply |
Over and under voltage / over temperature / overcurrent |
| Power outputs |
Overcurrent / DC / short circuit / over temperature |
| Interface |
|
| display/indicators |
1 TFT color touchscreen display (480 × 128 px) |
| Display |
1 encoding wheel with push button |
| Remote control and monitoring |
| L-Acoustics remote control software |
LA Network Manager |
| General purpose inputs and outputs (GPIO) |
3 in/out on 12 point terminal block |
| Third-party management solutions |
Q-SYS® / Crestron® |
| Operating conditions |
| Temperature |
-5º C / 23º F to +50º C / 122º F |
| Physical data |
| Height |
2U |
| Weight |
15.8 kg / 34.8 lb |
