PA multi-zone amplifier
☑ Class D amplifier and SMPS switched power supply
☑ Speaker output zones with volume control
☑ USB/FM player
☑ Emergency and mute input for connection to alarm and evacuation systems
☑ 24 V attenuators priority
FONESTAR MAX-120Z
939,06 €
Tasse incluse
Spedito entro 5/7 Giorni
PA multi-zone amplifier
☑ Class D amplifier and SMPS switched power supply
☑ Speaker output zones with volume control
☑ USB/FM player
☑ Emergency and mute input for connection to alarm and evacuation systems
☑ 24 V attenuators priority
close
| FEATURES: | Class D PA amplifier and SMPS switch-mode power supply. |
|---|---|
| USB/FM player. | |
| Microphone inputs with mix, gain and priority level control. | |
| Ring tone generator (Chime). | |
| 3 auxiliary inputs. | |
| Emergency and mute input for connection to alarm and evacuation systems. | |
| 24 V attenuator priority. | |
| Tone controls. | |
| 100 V, 70V and 4 Ω outputs. | |
| 3 output zones with volume control and Off. | |
| POWER: | 120 W RMS |
| RESPONSE: | 45-22,000 Hz -10 dB (@5W) |
| DISTORTION: | THD+N: <0.5% at 1 kHz |
| S/N RATIO: | Mic >75 dB, Line >83 dB, Aux >81 dB |
| PROTECTIONS: | Soft start, overcurrent, overload, temperature and short circuit |
| INPUTS: | CH 1 mic/line balanced with 48V phantom. Combo connector (XLR + 6.3mm) and euroblock. Contact closure ring tones. |
| CH 2 and 3 microphone/line balanced with Phantom 48V. Euroblock connector. Contact closure ring tones. | |
| Mic signal level: 5.6 mV RMS (-45 dBV) / 600 Ω. | |
| Line signal level: 250 mV RMS (-12 dBV) / 100k Ω. | |
| 3 x AUX. 2 x RCA connectors. Signal level 316 mV RMS (-10 dBV) / 47.000 Ω. | |
| 1 x emergency. Euroblock connector. Signal level: line 326 mV RMS (-10 dBV) or 100 V line. | |
| Mute (Emergency Priority) by contact closure. Euroblock connector. | |
| 1 x Amp-in. RCA connector. signal level 1.2 V RMS (+ 1.5 dBV). | |
| OUTPUTS: | 1 REC. 2 x RCA connector. Signal level 316 mV RMS (-10 dBV). Pre-master. |
| 1 Pre-out. RCA connector. Signal level 1.2 V RMS (+1.5 dBV). | |
| 100 V, 70 V or 4 Ω speaker output, or 3 zones of 100 V speakers with 7 positions volume selector and OFF. Euroblock connector. | |
| 1 attenuator priority, 24 V 100 mA and contact closure. Euroblock connector. | |
| IMPEDANCE: | 4 Ω and 100 V line (83Ω) and 70 V (41 Ω), euroblock |
| FUNCTIONS: | Priority of entries (in order of attenuation): |
| · 100V Emergency Input with selectable signal level (VOX) | |
| · Mute by closing contacts | |
| · Microphone 1 with selectable signal level (VOX) | |
| · Channels 2 | 3 with selectable signal level shared CH 2-3 (VOX) | |
| · Auxiliary Inputs | Player | |
| Light ignition ring in volume control, AUX input indicators, zones and player. | |
| Indicator lights for power, signal, clip, priority activation and protection | |
| Induction cooling, fanless. Silent and maintenance free | |
| PLAYER: | USB/FM player for background music playback |
| Autoplay, playback starts automatically when power is switched on | |
| Memory of last selected mode | |
| Play mode memory (random, repeat) | |
| CONTROLS: | Microphone volume |
| Master volume | |
| Aux or player input selector | |
| Zones with power on and 7 volume positions | |
| Tone: bass and treble (+/- 10 dB 100 Hz and 10k Hz) | |
| Mic/line/phantom selector, ring tones and priority | |
| Ring tone level (chime) | |
| Priority activation signal level (VOX) | |
| TEMPERATURE: | Operation: -10º ~ 40ºC |
| Storage: -20º ~ 60ºC | |
| MAXIMUM HUMIDITY: | 90% |
| POWER SUPPLY: | 230/115 V AC 50-60Hz |
| Power consumption: 175 W | |
| AC fuse 230 V 2 A / 115 V 4 A | |
| DIMENSIONS: | 430 x 89 x 320 mm depth. 2 U 19” rack |
| WEIGHT: | 7 kg |
| ACCESSORIES: | FM Antenna |
| Power cable | |
| Rack mounts |
